The ELC-30S is a resistive strain gage type load cell. It is used to determine load in rock bolts, tieback anchors etc through a centre hole. It is based on Wheatstone bridge principle and has eight 350 Ohm resistance strain gages, wired to form a 700 Ohm bridge, inside a cylinder of high steel strength. These eight gages are mounted around the circumference at 45 degrees to each other. The load cell is resistive to ingress of water and corrosive environment by sealing hermetically using the electron beam welding technique.
Our team will reach out to you in some time
Center hole load cell
Resistive strain gage
8 gages mounted to reduce positioning effect
To measure load in rock bolt anchors, tiebacks
Load/force
200/40, 500/52, 1000/78, 1000/105, 1500/85, 1500/130, 2000/105, 2000/155 kN/mm (ID); specify
Accuracy test, Overload test
Hermetically sealed with electron beam welding; great resistance to extraneous forces, long fatigue life, protected against dust, moisture and adverse environmental conditions
IP-68, water resistant up to 10 mwc
Depends on range
